Abssac was successful in being able to replicate the part and deliver the new part ready to fit into the repaired machine.Īs standard splined shaft are available from 14mm to 54mm in diameter with either 6 or 8 spline formats. The only information available was to be gathered from the broken and distorted sample sent to us after a catastrophic failure at the paper mill.
Manufactured from EN24T steel the customer did not have any technical drawings from which we could quote from. Measuring a massive 150mm in diameter, with 8 splines along its 2 metres length and weighing in at 250kg !.
Machined from high grade EN8 steel in diameters of 14mm to 54mm as standard and supplied in lengths up to 3 metres enables us to supply into the most high load and long life expectancy linear applications.Ībssac has recently supplied one of the largest splined shafts to date.
